Our high-efficiency Micron Filter ensures superior purity by removing particles down to 0.1μm from liquids and gases. Perfect for pharmaceutical, food, and chemical industries, it features fast flow, low clogging, and corrosion resistance. Boost your sanitary process reliability—explore our solutions now
| Filter element specifications | 5", 10", 15", 20", 30", 40" |
| Number of filter elements | 1core, 2cores, 3cores, 5cores, 7cores, 9cores, 12cores, 24cores, etc. |
| Filter element material | PP; PES; PTFE; PVDF; N6; N66; CN-CA; ACF. |
| Filter element interface | 220, 222, 226. |
| Filter element precision (μm) | 0.05, 0.1, 0.2, 0.45, 0.65, etc. |
| Shell material | 304/1.4301; 316L/1.4404, ASME BPE 316L 1.4435 NB2 Fe≤0.5% |
| Pressure | Vacuum to 10bar (1.0 MPa) |
| Temperature | -20℃ to +150℃, Depending on the seal material |
| Sealing | EPDM FKM HNBR PTFE |
| Connection standard | DIN SMS ISO IDF RJT BS4825 ASME BPE 3A DIN11864 DIN11853 |
| Connection method | thread, clamp, welding, flange |
| Finish | Ra≤0.6μm, MP=Ra≤0.3μm, EP=Ra≤0.3μm |
| Certification | FDA 177.2600, Glass II USP Glass VI Chapter 88, GB4806.11, EG VO/1935-2004, PED/97/23/EC. |
