The anti-mixing tank bottom valve is a high-cleanliness, online cleaning and sterilization integrated anti-mixing tank bottom valve.
Double seal protection, leakage can be found, self-draining, prevent media mixed contamination.
| Specifications | 1.5"-6", DN40-DN150 |
| Material | 316L/1.4404, ASME BPE 316L 1.4435 NB2 Fe≤0.5% |
| Pressure | vacuum to 10bar (1.0 MPa) |
| Temperature | -20℃ to +150℃, Depending on the seal material |
| Sealing | EPDM FKM HNBR |
| Connection standard | DIN SMS ISO IDF RJT BS4825 ASME BPE 3A DIN11864 DIN11853 |
| Connection method | Thread, clamp, welding, flange |
| Drive mode | pneumatic |
| Finish | Ra≤0.6μm; MP=Ra≤0.3μm; EP=Ra≤0.3μm |
| Certification | FDA 177.2600; 3A-85-03; Glass II USP Glass VI Chapter 88; GB4806.11; EG VO/1935-2004; PED/97/23/EC. |
